Van Bi NDV Model F104NB

Nhãn hiệu: NDV
Xuất xứ: Nhật Bản

Mã sản phẩm (Model/Fig)	F104NB
Hoạt động (Oper.)	Vận hành bằng tay / Manual operated(Lever type)
Vật liệu thân van (Body)	Gang dẻo - Ductile iron(FCD)
Vật liệu lớp phủ (Lining)	-
Vật liệu đĩa / bi (Disk/Ball)	-SCS13A,14A,16A
Vật liệu đệm màng (Diaphragm/Seat )	PTFE, Reinforced PTFE
Kích thước (Size) mm / DN / A	15〜200
Kiểu kết nối (End Connection)	Nối bích JIS 10K RF (Flanged JIS10K RF) hoặc ANSI class 150RF (ANSI Class 150 RF)
Ghi chú (Remarks)	-

Drawing Data Download

Nominal Diameter		Actuator Code	Download
B	A	Actuator Code	Download
1/2	15	-	CAD	Drawing
3/4	20	-	CAD
1	25	-	CAD
1･1/2	40	-	CAD
2	50	-	CAD
2･1/2	65	-	CAD
3	80	-	CAD
4	100	-	CAD
5	125	-	CAD
6	150	-	CAD
8	200	-	CAD

*Hình ảnh và bản vẽ trong trang web này chỉ mang tính chất tham khảo. Vui lòng liên hệ với bộ phận bán hàng của chúng tôi để biết thêm chi tiết.

Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
F104NB	15〜200	2way	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
F104NB	15〜200	2way	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
F104NB	15〜200	2way	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(10K)	Detail
F104NB	15〜200	2way	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
F107NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
F112NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
F112NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
F112NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
F112NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(10K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(20K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(150Lb)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(300Lb)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	Metal	Flange(10K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	Metal	Flange(20K)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	Metal	Flange(150Lb)	Detail
F113NB	15〜200	2way	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	Metal	Flange(300Lb)	Detail
FG104NB	100〜200	2way	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
FG104NB	100〜200	2way	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
FG104NB	100〜200	2way	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(10K)	Detail
FG104NB	100〜200	2way	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FG107NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FG112NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FG112NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FG112NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FG112NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(10K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(20K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(150Lb)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(300Lb)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	Metal	Flange(10K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	Metal	Flange(20K)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	Metal	Flange(150Lb)	Detail
FG113NB	100〜200	2way	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	Metal	Flange(300Lb)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
E112JNC	15〜100	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
E112JNC	20〜100	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
E112JNC	15〜100	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(20K)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
E112JNC	20〜100	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(300Lb)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(20K)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(150Lb)	Detail
E112JNC	15〜100	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(300Lb)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
E112JNC	15〜200	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
E112JNC	15〜100	2way(Jacketed)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FEX107NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(20K)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(300Lb)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(20K)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(150Lb)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(300Lb)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
FEX112NB	15〜150	2way(extended gland)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
V104	25〜200	2way(V port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
V104	25〜200	2way(V port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
V104	25〜200	2way(V port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
V104	25〜200	2way(V port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
V107	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
V107	125〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
V107	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
V107	125〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
V107	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
V107	125〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
V107	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
V107	125〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
V112	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
V112	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
V112	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
V112	125〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
V112	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
V112	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
V112	25〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
V112	125〜200	2way(V port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
VG104	100〜200	2way(V port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
VG104	100〜200	2way(V port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
VG104	100〜200	2way(V port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
VG104	100〜200	2way(V port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
VG107	100〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
VG107	125〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
VG107	100〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
VG107	125〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
VG107	100〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
VG107	125〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
VG107	100〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
VG107	125〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
VG112	120〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
VG112	120〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
VG112	120〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
VG112	125〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
VG112	120〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
VG112	120〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
VG112	120〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
VG112	125〜200	2way(V port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
E304NB-L2	15〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
E304NB-L2	15〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
E307NB-L2	15〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
E307NB-L2	15〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
E312NB-L2	15〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
E312NB-L2	15〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
E312NB-L2	15〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
E312NB-L2	15〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
E304NB-T4	15〜100	3way(T shaped port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
E307NB-T4	15〜100	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
E312NB-T4	15〜100	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
E312NB-T4	15〜100	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
E304NB-L4	15〜100	3way(L shaped port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
E307NB-L4	15〜100	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
E312NB-L4	15〜100	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
E312NB-L4	15〜100	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EG304NB-L2	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EG304NB-L2	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
EG307NB-L2	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EG307NB-L2	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
EG312NB-L2	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EG312NB-L2	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EG312NB-L2	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
EG312NB-L2	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
EG304NB-T4	80〜100	3way(T shaped port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EG307NB-T4	80〜100	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EG312NB-T4	80〜100	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EG312NB-T4	80〜100	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EG304NB-L4	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EG307NB-L4	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EG307NB-L4	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EG312NB-L4	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
EG312NB-L4	80〜100	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EG304N-T3	125〜200	3way(T shaped port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EG304N-T3	125〜200	3way(T shaped port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EG307N-T3	125〜200	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EG307N-T3	125〜200	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EG312N-T3	125〜200	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EG312N-T3	125〜200	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EG313N-T3	125〜200	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EG313N-T3	125〜200	3way(T shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EG304N-L3	125〜200	3way(L shaped port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EG304N-L3	125〜200	3way(L shaped port)	Manual O.P.(Gear)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EG307N-L3	125〜200	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EG307N-L3	125〜200	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EG312N-L3	125〜200	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EG312N-L3	125〜200	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EG313N-L3	125〜200	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EG313N-L3	125〜200	3way(L shaped port)	Manual O.P.(Gear)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
E304N-T3	125〜200	3way(T shaped port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
E304N-T3	125〜200	3way(T shaped port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
E307N-T3	125〜200	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
E307N-T3	125〜200	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
E312N-T3	125〜200	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
E312N-T3	125〜200	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
E313N-T3	125〜200	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
E313N-T3	125〜200	3way(T shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
E304N-L3	125〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
E304N-L3	125〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
E307N-L3	125〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
E307N-L3	125〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
E312N-L3	125〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
E312N-L3	125〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
E313N-L3	125〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
E313N-L3	125〜200	3way(L shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FPO1104NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
FPO1104NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FPO1107NB	15〜150	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FPO1107NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FPO1107NB	15〜150	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FPO1112NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FPO1112NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FPO1112NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(10K)	Detail
FPO1113NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(150Lb)	Detail
FPC1104NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
FPC1104NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FPC1107NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FPC1112NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FPC1112NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FPC1113NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
FPC1113NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
FPC1113NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FPC1113NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
FPC1113NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
FPC1113NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
FPC1113NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPC1113NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FPN1112NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FPN1112NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
FPN1104NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
FPN1104NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
EPO1304NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPO1304NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
EPO1307NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPO1307NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
EPO1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPO1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPO1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
EPO1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
EPO1304NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPO1307NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPO1312NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPO1312NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPO1304NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPO1307NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPO1312NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPO1312NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPC1304NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPC1304NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
EPC1307NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPC1307NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
EPC1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPC1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPC1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
EPC1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
EPC1304NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPC1307NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPC1312NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPC1312NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPC1304NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPC1307NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPC1312NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPC1312NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPN1304NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPN1304NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
EPN1307NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPN1307NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
EPN1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPN1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPN1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
EPN1312NB-L2	15〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
EPN1304NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPN1307NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPN1312NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPN1312NB-T4	15〜100	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPN1304NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPN1307NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPN1312NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPN1312NB-L4	15〜100	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPO1304N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPO1304N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EPO1307N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPO1307N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EPO1312N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPO1312N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPO1313N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPO1313N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EPO1304N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPO1304N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EPO1307N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPO1307N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EPO1312N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPO1312N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPO1313N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPO1313N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EPC1304N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPC1304N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EPC1307N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPC1307N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EPC1312N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPC1312N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPC1313N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPC1313N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EPC1304N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPC1304N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EPC1307N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPC1307N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EPC1312N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPC1312N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPC1313N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPC1313N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EPN1304N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPN1304N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EPN1307N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPN1307N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EPN1312N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPN1312N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
EPN1313N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPN1313N-T3	125〜200	3way(T shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EPN1304N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPN1304N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EPN1307N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPN1307N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EPN1312N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPN1312N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPN1313N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPN1313N-L3	125〜200	3way(L shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
VPO1104	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
VPO1104	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
VPO1104	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
VPO1104	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
VPO1107	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
VPO1107	125〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
VPO1107	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
VPO1107	125〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
VPO1107	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
VPO1107	125〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
VPO1107	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
VPO1107	125〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
VPO1112	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
VPO1112	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
VPO1112	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
VPO1112	100〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
VPO1112	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
VPO1112	25〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
VPO1112	125〜200	2way(V port)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
VPC1104	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
VPC1104	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
VPC1104	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
VPC1104	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
VPC1107	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
VPC1107	125〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
VPC1107	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
VPC1107	125〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
VPC1107	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
VPC1107	125〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
VPC1107	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
VPC1107	125〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
VPC1112	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
VPC1112	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
VPC1112	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
VPC1112	100〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
VPC1112	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
VPC1112	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
VPC1112	25〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
VPC1112	100〜200	2way(V port)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
VPN1104	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
VPN1104	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
VPN1104	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
VPN1104	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
VPN1107	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
VPN1107	125〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
VPN1107	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
VPN1107	125〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
VPN1107	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
VPN1107	125〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
VPN1107	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
VPN1107	125〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
VPN1112	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
VPN1112	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
VPN1112	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
VPN1112	125〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
VPN1112	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
VPN1112	25〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
VPN1112	125〜200	2way(V port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPO1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
EPO1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(20K)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
EPO1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(300Lb)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
EPO1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(20K)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(150Lb)	Detail
EPO1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(300Lb)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
EPO1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
EPO1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
EPO1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
EPC1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPC1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EPC1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPC1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
EPC1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
EPC1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(20K)	Detail
EPC1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
EPC1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(300Lb)	Detail
EPC1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
EPC1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(20K)	Detail
EPC1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(150Lb)	Detail
EPC1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(300Lb)	Detail
EPC1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
EPC1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
EPC1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
EPC1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
EPN1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPN1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EPN1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPN1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
EPN1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
EPN1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(20K)	Detail
EPN1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(150Lb)	Detail
EPN1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(300Lb)	Detail
EPN1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
EPN1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(20K)	Detail
EPN1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(150Lb)	Detail
EPN1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(300Lb)	Detail
EPN1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
EPN1112JNC	15〜100	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
EPN1112JNC	15〜200	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
EPN1112JNC	20〜100	2way(Jacketed)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FEXPO1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FEXPO1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FEXPO1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FEXPO1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FEXPO1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(Reverse acting)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FEXPC1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FEXPC1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FEXPC1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FEXPC1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FEXPC1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(direct acting)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FEXPN1107NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FEXPN1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FEXPN1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FEXPN1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FEXPN1112NB	15〜150	2way(extended gland)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
ETON1101N	125〜200	2way(for shield use)	Hydraulic O.P.	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
ETON1105N	125〜200	2way(for shield use)	Hydraulic O.P.	×	Cast steel(SCPH2)	×	PTFE	Flange(10K)	Detail
EKTON1101N	200〜350	2way(for shield use)	Hydraulic O.P.	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
EKTON1105N	200〜350	2way(for shield use)	Hydraulic O.P.	×	Cast steel(SCPH2)	×	PTFE	Flange(10K)	Detail
ETRH101N	125〜200	2way(for shield use)	Manual O.P.(Lever)	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
ETRH105N	125〜200	2way(for shield use)	Manual O.P.(Lever)	×	Cast steel(SCPH2)	×	PTFE	Flange(10K)	Detail
EKTGRH101N	250〜350	2way(for shield use)	Manual O.P.(Gear)	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
EKTGRH105N	250〜350	2way(for shield use)	Manual O.P.(Gear)	×	Cast steel(SCPH2)	×	PTFE	Flange(10K)	Detail
Y307-L3	25〜300	3way(Y shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
Y307-L3	25〜300	3way(Y shaped port)	Manual O.P.(Lever)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
YWN1307-L3	25〜300	3way(Y shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
YWN1307-L3	25〜300	3way(Y shaped port)	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EKTPN1101N	250	2way(for shield use)	Pneumatic O.P.(Double acting)	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
EKTPN1105N	250〜350	2way(for shield use)	Pneumatic O.P.(Double acting)	×	Cast steel(SCPH2)	×	PTFE	Flange(10K)	Detail
EKTGJ101N	250〜350	2way(for shield use)	Manual O.P.(Gear)	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
EKTGJ105N	250〜350	2way(for shield use)	Manual O.P.(Gear)	×	Cast steel(SCPH2)	×	PTFE	Flange(10K)	Detail
ET101N	125〜200	2way(for shield use)	Manual O.P.(Lever)	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
ETGJ101N	125〜200	2way(for shield use)	Manual O.P.(Gear)	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
ETGRH101N	125〜200	2way(for shield use)	Manual O.P.(Gear)	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
ETPN1101N	150〜200	2way(for shield use)	Pneumatic O.P.(Double acting)	×	Cast iron(FC200)	×	PTFE	Flange(10K)	Detail
FSR4104NB	15〜150	2way	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
FSR4104NB	15〜150	2way	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
FSR4104NB	15〜150	2way	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(10K)	Detail
FSR4104NB	15〜150	2way	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FSR4107NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FSR4112NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FSR4112NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FSR4112NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FSR4112NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(10K)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(20K)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(150Lb)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(300Lb)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	Metal	Flange(10K)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	Metal	Flange(20K)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	Metal	Flange(150Lb)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	Metal	Flange(300Lb)	Detail
FMSJ4104NB	15〜200	2way	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
FMSJ4104NB	15〜200	2way	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
FMSJ4104NB	15〜200	2way	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(10K)	Detail
FMSJ4104NB	15〜200	2way	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FMSJ4107NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FMSJ4112NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FMSJ4112NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FMSJ4112NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FMSJ4112NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(10K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(20K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(150Lb)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(300Lb)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	Metal	Flange(10K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	Metal	Flange(20K)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	Metal	Flange(150Lb)	Detail
FMSJ4113NB	15〜200	2way	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	Metal	Flange(300Lb)	Detail
FSD4104NB	125〜200	2way	Motor O.P.(LTKD type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
FSD4104NB	125〜200	2way	Motor O.P.(LTKD type)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
FSD4104NB	125〜200	2way	Motor O.P.(LTKD type)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(10K)	Detail
FSD4104NB	125〜200	2way	Motor O.P.(LTKD type)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FSD4107NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FSD4112NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FSD4112NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FSD4112NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FSD4112NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(10K)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(20K)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(150Lb)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(300Lb)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	Metal	Flange(10K)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	Metal	Flange(20K)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	Metal	Flange(150Lb)	Detail
FSD4113NB	125〜200	2way	Motor O.P.(LTKD type)	×	Stainless steel(SCS16)	×	Metal	Flange(300Lb)	Detail
FPMK4104NB	15〜200	2way	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
FPMK4104NB	15〜200	2way	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(10K)	Detail
FPMK4104NB	15〜200	2way	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(10K)	Detail
FPMK4104NB	15〜200	2way	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(10K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(20K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE + metal ring	Flange(300Lb)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
FPMK4107NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
FPMK4112NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
FPMK4112NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE + metal ring	Flange(10K)	Detail
FPMK4112NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FPMK4112NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(300Lb)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(10K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(20K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE + metal ring	Flange(300Lb)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(10K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(20K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(150Lb)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(300Lb)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	Metal	Flange(10K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	Metal	Flange(20K)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	Metal	Flange(150Lb)	Detail
FPMK4113NB	15〜200	2way	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	Metal	Flange(300Lb)	Detail
VSR4104	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
VSR4104	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
VSR4104	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
VSR4104	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
VSR4107	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
VSR4107	125〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
VSR4107	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
VSR4107	125〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
VSR4107	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
VSR4107	125〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
VSR4107	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
VSR4107	125〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
VSR4112	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
VSR4112	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
VSR4112	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
VSR4112	125〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
VSR4112	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
VSR4112	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
VSR4112	25〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
VSR4112	125〜150	2way(V port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
VMSJ4104	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
VMSJ4104	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	Metal	Flange(10K)	Detail
VMSJ4104	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
VMSJ4107	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
VMSJ4107	125〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(20K)	Detail
VMSJ4107	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
VMSJ4107	125〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(300Lb)	Detail
VMSJ4107	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Metal	Flange(10K)	Detail
VMSJ4107	125〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Metal	Flange(20K)	Detail
VMSJ4107	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Metal	Flange(150Lb)	Detail
VMSJ4107	125〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	Metal	Flange(300Lb)	Detail
VMSJ4112	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
VMSJ4112	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
VMSJ4112	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
VMSJ4112	125〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(300Lb)	Detail
VMSJ4112	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	Metal	Flange(10K)	Detail
VMSJ4112	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	Metal	Flange(20K)	Detail
VMSJ4112	25〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	Metal	Flange(150Lb)	Detail
VMSJ4112	125〜200	2way(V port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	Metal	Flange(300Lb)	Detail
FSR4113NB	15〜150	2way	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(20K)	Detail
EMSJ4312N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
ESR4304NB-L2	15〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
ESR4304NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
ESR4304N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
ESR4304NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
ESR4304N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
ESR4304N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
ESR4304N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
ESR4307NB-L2	15〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
ESR4307NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
ESR4307N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
ESR4307NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
ESR4307N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
ESR4307N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
ESR4307N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
ESR4312NB-L2	15〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
ESR4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
ESR4312N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
ESR4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
ESR4312N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
ESR4312NB-L2	15〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
ESR4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
ESR4312N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
ESR4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
ESR4312N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
ESR4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
ESR4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
ESR4313NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
ESR4313N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
ESR4313NB-T4	15〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
ESR4313N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
ESR4313N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
ESR4313N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRH type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EMSJ4304NB-L2	15〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EMSJ4304NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EMSJ4304N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EMSJ4304NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EMSJ4304N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EMSJ4304N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EMSJ4304N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EMSJ4307NB-L2	15〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EMSJ4307NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EMSJ4307N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EMSJ4307NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EMSJ4307N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EMSJ4307N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EMSJ4307N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EMSJ4312NB-L2	15〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EMSJ4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EMSJ4312N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EMSJ4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EMSJ4312NB-L2	15〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EMSJ4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EMSJ4312N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EMSJ4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EMSJ4312N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EMSJ4312NB-L2	15〜100	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EMSJ4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EMSJ4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EMSJ4313NB-L4	15〜100	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EMSJ4313N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EMSJ4313NB-T4	15〜100	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EMSJ4313N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EMSJ4313N-L3	125〜200	3way(L shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EMSJ4313N-T3	125〜200	3way(T shaped port)	Motor O.P.(SRJ type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EPMK4304NB-L2	15〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPMK4304NB-L4	15〜100	3way(L shaped port)	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPMK4304N-L3	125〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPMK4304NB-T4	15〜100	3way(T shaped port)	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPMK4304N-T3	125〜200	3way(T shaped port)	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(10K)	Detail
EPMK4304N-L3	125〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EPMK4304N-T3	125〜200	3way(T shaped port)	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
EPMK4307NB-L2	15〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPMK4307NB-L4	15〜100	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPMK4307N-L3	125〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPMK4307NB-T4	15〜100	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPMK4307N-T3	125〜200	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(10K)	Detail
EPMK4307N-L3	125〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EPMK4307N-T3	125〜200	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS13)	×	PTFE	Flange(150Lb)	Detail
EPMK4312NB-L2	15〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPMK4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPMK4312N-L3	125〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPMK4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPMK4312N-T3	125〜200	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(10K)	Detail
EPMK4312NB-L2	15〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPMK4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPMK4312N-L3	125〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPMK4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPMK4312N-T3	125〜200	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(150Lb)	Detail
EPMK4312NB-L2	15〜100	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EPMK4312NB-L4	15〜100	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EPMK4312NB-T4	15〜100	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS14)	×	PTFE	Flange(20K)	Detail
EPMK4313NB-L4	15〜100	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPMK4313N-L3	125〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPMK4313NB-T4	15〜100	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPMK4313N-T3	125〜200	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(10K)	Detail
EPMK4313N-L3	125〜200	3way(L shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
EPMK4313N-T3	125〜200	3way(T shaped port)	Motor O.P.(PMK type)	×	Stainless steel(SCS16)	×	PTFE	Flange(150Lb)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(10K)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(20K)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(150Lb)	Detail
FPN1107NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS13)	×	Carbon + metal ring	Flange(300Lb)	Detail
FPN1112NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS14)	×	Carbon + metal ring	Flange(10K)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(10K)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(20K)	Detail
Product Code	Nominal Diameter	Model	Operation	Ancillary Device	Body Material	Lining Material	Diaphragm/ Seat Material	End Connection
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(150Lb)	Detail
FPN1113NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Stainless steel(SCS16)	×	Carbon + metal ring	Flange(300Lb)	Detail
F104NB	15〜200	2way	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
F104NB	15〜200	2way	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(150Lb)	Detail
F104NB	15〜200	2way	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(150Lb)	Detail
F104NB	15〜200	2way	Manual O.P.(Lever)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
FPO1104NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
FPO1104NB	15〜200	2way	Pneumatic O.P.(Reverse acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPC1104NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
FPC1104NB	15〜200	2way	Pneumatic O.P.(direct acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPN1104NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
FPN1104NB	15〜200	2way	Pneumatic O.P.(Double acting)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(150Lb)	Detail
FSR4104NB	15〜150	2way	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
FSR4104NB	15〜150	2way	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(150Lb)	Detail
FSR4104NB	15〜150	2way	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(150Lb)	Detail
FSR4104NB	15〜150	2way	Motor O.P.(SRH type)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
FMSJ4104NB	15〜200	2way	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
FMSJ4104NB	15〜200	2way	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(150Lb)	Detail
FMSJ4104NB	15〜200	2way	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(150Lb)	Detail
FMSJ4104NB	15〜200	2way	Motor O.P.(SRJ type)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
FSD4104NB	125〜200	2way	Motor O.P.(LTKD type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
FSD4104NB	125〜200	2way	Motor O.P.(LTKD type)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(150Lb)	Detail
FSD4104NB	125〜200	2way	Motor O.P.(LTKD type)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(150Lb)	Detail
FSD4104NB	125〜200	2way	Motor O.P.(LTKD type)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
FPMK4104NB	15〜200	2way	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE	Flange(150Lb)	Detail
FPMK4104NB	15〜200	2way	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	PTFE + metal ring	Flange(150Lb)	Detail
FPMK4104NB	15〜200	2way	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	Carbon + metal ring	Flange(150Lb)	Detail
FPMK4104NB	15〜200	2way	Motor O.P.(PMK type)	×	Ductile iron(FCD)	×	Metal	Flange(150Lb)	Detail
