PINCH VALVES ORBINOX MODEL PA

PA MODEL

Heavy-duty full bore pinch valve

The PA model pinch valve is a heavy-duty enclosed construction full bore valve that employs elastomer sleeves for flow shut-off and control in applications with abrasive and corrosive slurries. The sleeve is the only part in contact with the media, no other mechanical parts are required, and it is a maintenance free part.

The design of the sleeve assures non-clogging shutoff on suspended solids in industries such as:

• Mining
• Wastewater treatment
• Chemical plants
• Pulp and paper
• Power plants
• Cement and ceramic
• Etc.

SIZES
DN 1”/25mm to 12”/DN 300mm

WORKING PRESSURE
DN   1”/ 25mm to   6”/150mm   10 bar
DN   8”/200mm  8,5 bar
DN 10”/250mm  7 bar
DN 12”/300mm  6 bar

FACE TO FACE
Same face-to-face distance as that for gate, plug or ball valves up to 6”/DN150 (Class 150)

STANDARD FLANGE CONNECTION
EN1092 PN10
ANSI B16.5 (class 150)
