Product
Code | Nominal
Diameter | Model | Operation | Ancillary
Device | Body
Material | Lining
Material | Diaphragm/
Seat Material | End
Connection | |
| 501N | 15〜80 | Straight type | Manual O.P. | - | Cast iron(FC200) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 504N | 15〜80 | Straight type | Manual O.P. | - | Ductile iron(FCD) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 507N | 15〜80 | Straight type | Manual O.P. | - | Stainless steel(SCS13) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 512N | 15〜80 | Straight type | Manual O.P. | - | Stainless steel(SCS14) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 513N | 15〜80 | Straight type | Manual O.P. | - | Stainless steel(SCS16) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 530N | 15〜80 | Straight type | Manual O.P. | - | Cast iron(FC200) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 530(04)N | 15〜80 | Straight type | Manual O.P. | - | Ductile iron(FCD) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 533N | 15〜80 | Straight type | Manual O.P. | - | Cast iron(FC200) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 533(04)N | 15〜80 | Straight type | Manual O.P. | - | Ductile iron(FCD) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 536N | 15〜80 | Straight type | Manual O.P. | - | Cast iron(FC200) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 536(04)N | 15〜80 | Straight type | Manual O.P. | - | Ductile iron(FCD) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 535N | 15〜80 | Straight type | Manual O.P. | - | Cast iron(FC200) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 535(04)N | 15〜80 | Straight type | Manual O.P. | - | Ductile iron(FCD) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 501 | 100〜250 | Straight type | Manual O.P. | - | Cast iron(FC200) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 504 | 100〜250 | Straight type | Manual O.P. | - | Ductile iron(FCD) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 507 | 100〜250 | Straight type | Manual O.P. | - | Stainless steel(SCS13) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 512 | 100〜250 | Straight type | Manual O.P. | - | Stainless steel(SCS14) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 513 | 100〜250 | Straight type | Manual O.P. | - | Stainless steel(SCS16) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 530 | 100〜250 | Straight type | Manual O.P. | - | Cast iron(FC200) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 530(04) | 100〜250 | Straight type | Manual O.P. | - | Ductile iron(FCD) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 533 | 100〜250 | Straight type | Manual O.P. | - | Cast iron(FC200) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 533(04) | 100〜250 | Straight type | Manual O.P. | - | Ductile iron(FCD) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 536 | 100〜250 | Straight type | Manual O.P. | - | Cast iron(FC200) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 536(04) | 100〜250 | Straight type | Manual O.P. | - | Ductile iron(FCD) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 535 | 100〜250 | Straight type | Manual O.P. | - | Cast iron(FC200) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 535(04) | 100〜250 | Straight type | Manual O.P. | - | Ductile iron(FCD) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 401NB | 15〜100 | Weir type | Manual O.P. | - | Cast iron(FC200) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 401NB | 15〜100 | Weir type | Manual O.P. | - | Cast iron(FC200) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 404NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 404NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 407NB | 15〜100 | Weir type | Manual O.P. | - | Stainless steel(SCS13) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 407NB | 15〜100 | Weir type | Manual O.P. | - | Stainless steel(SCS13) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 412NB | 15〜100 | Weir type | Manual O.P. | - | Stainless steel(SCS14) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 412NB | 15〜100 | Weir type | Manual O.P. | - | Stainless steel(SCS14) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 413NB | 15〜100 | Weir type | Manual O.P. | - | Stainless steel(SCS16) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 413NB | 15〜100 | Weir type | Manual O.P. | - | Stainless steel(SCS16) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 430NB | 15〜100 | Weir type | Manual O.P. | - | Cast iron(FC200) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 430NB | 15〜100 | Weir type | Manual O.P. | - | Cast iron(FC200) | Hard natural rubber lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 430(04)NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 430(04)NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Hard natural rubber lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 433NB | 15〜100 | Weir type | Manual O.P. | - | Cast iron(FC200) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 433(04)NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 436NB | 15〜100 | Weir type | Manual O.P. | - | Cast iron(FC200) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 436(04)NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 435NB | 15〜100 | Weir type | Manual O.P. | - | Cast iron(FC200) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 435(04)NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 459(M)NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | PFA Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 459(2S)NB | 15〜80 | Weir type | Manual O.P. | - | Stainless steel(SCS13) | PFA Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 460NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | ETFE Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 440(04)NB | 15〜100 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Glass lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 480(04)NB | 15〜80 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Porcelain(Mullite) lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 401 | 125〜300 | Weir type | Manual O.P. | - | Cast iron(FC200) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 401 | 125〜250 | Weir type | Manual O.P. | - | Cast iron(FC200) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 404 | 125〜300 | Weir type | Manual O.P. | - | Ductile iron(FCD) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 404 | 125〜250 | Weir type | Manual O.P. | - | Ductile iron(FCD) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 407 | 125〜300 | Weir type | Manual O.P. | - | Stainless steel(SCS13) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 407 | 125〜250 | Weir type | Manual O.P. | - | Stainless steel(SCS13) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 412 | 125〜300 | Weir type | Manual O.P. | - | Stainless steel(SCS14) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 412 | 125〜250 | Weir type | Manual O.P. | - | Stainless steel(SCS14) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 413 | 125〜300 | Weir type | Manual O.P. | - | Stainless steel(SCS16) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 413 | 125〜250 | Weir type | Manual O.P. | - | Stainless steel(SCS16) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 430 | 125〜300 | Weir type | Manual O.P. | - | Cast iron(FC200) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 430 | 125〜250 | Weir type | Manual O.P. | - | Cast iron(FC200) | Hard natural rubber lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 430(04) | 125〜300 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 430(04) | 125〜250 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Hard natural rubber lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 433 | 125〜300 | Weir type | Manual O.P. | - | Cast iron(FC200) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 433(04) | 125〜300 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 436 | 125〜300 | Weir type | Manual O.P. | - | Cast iron(FC200) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 436(04) | 125〜300 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 435 | 125〜300 | Weir type | Manual O.P. | - | Cast iron(FC200) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 435(04) | 125〜300 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 459(M) | 125〜250 | Weir type | Manual O.P. | - | Ductile iron(FCD) | PFA Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| 440(04) | 125〜250 | Weir type | Manual O.P. | - | Ductile iron(FCD) | Glass lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L401NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Cast iron(FC200) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L401NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Cast iron(FC200) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L404NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L404NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L407NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Stainless steel(SCS13) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L407NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Stainless steel(SCS13) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L412NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Stainless steel(SCS14) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L412NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Stainless steel(SCS14) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L413NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Stainless steel(SCS16) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L413NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Stainless steel(SCS16) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L430NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Cast iron(FC200) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L430NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Cast iron(FC200) | Hard natural rubber lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L430(04)NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L430(04)NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | Hard natural rubber lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L433NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Cast iron(FC200) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L433(04)NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L436NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Cast iron(FC200) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L436(04)NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L435NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Cast iron(FC200) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L435(04)NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L459(M)NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | PFA Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L459(2S)NB | 15〜80 | Weir type | Manual O.P. | L(Lock nut) | Stainless steel(SCS13) | PFA Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L460NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | ETFE Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L440(04)NB | 15〜100 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | Glass lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| L480(04)NB | 15〜80 | Weir type | Manual O.P. | L(Lock nut) | Ductile iron(FCD) | Porcelain(Mullite) lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S401NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Cast iron(FC200) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S401NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Cast iron(FC200) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S404NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S404NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S407NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Stainless steel(SCS13) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S407NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Stainless steel(SCS13) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S412NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Stainless steel(SCS14) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S412NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Stainless steel(SCS14) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S413NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Stainless steel(SCS16) | - | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S413NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Stainless steel(SCS16) | - | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S430NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Cast iron(FC200) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S430NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Cast iron(FC200) | Hard natural rubber lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S430(04)NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | Hard natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S430(04)NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | Hard natural rubber lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S433NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Cast iron(FC200) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S433(04)NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | Soft natural rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S436NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Cast iron(FC200) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S436(04)NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | Butyl rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S435NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Cast iron(FC200) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S435(04)NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | Chloroprene rubber lined | Rubber | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S459(M)NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | PFA Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S459(2S)NB | 15〜80 | Weir type | Manual O.P. | S(Opening indicator) | Stainless steel(SCS13) | PFA Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S460NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | ETFE Lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S440(04)NB | 15〜100 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | Glass lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
| S480(04)NB | 15〜80 | Weir type | Manual O.P. | S(Opening indicator) | Ductile iron(FCD) | Porcelain(Mullite) lined | PTFE | Flange(10K FF) / ANSI Cl125 FF | Detail |
