MODEL: BMU-3 - BỘ LẮP CHO ĐỒNG HỒ NƯỚC VENN NHẬT

BỘ LẮP CHO ĐỒNG HỒ NƯỚC VENN NHẬT
MODEL: BMU-3


Anh chị vui lòng gọi điện hoặc gởi nhu cầu qua ZALO số 0902720814 / 0907450506 / 0766226161 gặp nhân viên kinh doanh để được tư vấn kỹ thuật và báo giá cụ thể hoặc gửi email vào hòm thư: sales@pm-e.vn / info@pm-e.vn.


Khối lượng:
1.000.000 đ
Số lượng

Pressure reducing valve (for water / liquid / door-to-door water supply), constant flow valve, water hammer preventer
BMU-3 type meter unit

This product is a unitized product of a water stopcock around the meter, a pressure reducing valve, a telescopic pipe function, a check valve, and a pedestal in the pipe shaft of an apartment house.
Since the meter is connected by crimping by operating the handle, it is easy to install and remove.

* Specifications may differ depending on each business entity, so please contact us.

Where to use: housing complex

Major features

  • Lightweight and compact design considering workability in a narrow pipe shaft.
  • A tool-free crimping type that allows you to install and remove the meter by operating the handle.
  • It corresponds to the vertical / horizontal piping and the flow direction from the right / left.
  • The pedestal part has excellent corrosion resistance.
  • A water stop cap can be attached to the water stopcock part.


Specification:

  • The pressure gauge fitting can be used in combination with the opposite plug.
  • The pressure gauge of the pressure reducing valve can be selected as A type or D type as an option. (The maximum scale of the pressure gauge is 0.5MPa.)
  • We also manufacture meter surfaces with a nominal diameter of 13: 165 mm and a nominal diameter of 25: 210 mm

Product code BMU3-F
Valve type Meter unit
type No pressure reducing valve
Nominal diameter 13 ・ 25 (33/64.1)
Applicable fluid Tap water
Fluid temperature At normal temperature
Primary side applied pressure 1.0MPa or less
End connection JIS Rc screw (built-in pipe end anticorrosion core)
Pressure resistance 1.75MPa
Material body Bronze casting, etc.
Material pedestal Steel plate / steel pipe
