VAN AN TOÀN ZETKAMA PN16 FIG 240

1.000.000 đ

VAN AN TOÀN ZETKAMA PN16 FIG 240

VAN AN TOÀN ZETKAMA PN16 (BA LAN)

Model: 240 PROPORTIONAL
Thân: Gang JL1040
Đĩa: inox
Kết nối: Bích PN16

Material:Grey cast iron, cast steel, acid resistant steel
Nominal pressure:16, 40 bar
Nominal diameter:15-200 mm
Temperature range:-196…+400°C
Working position:Vertical

Proportional angle spring safety valve with flanged ends with a high degree of tightness. The body of the product, depending on the model, may be made of grey cast iron (DN 15-200 for pressure up to 16 bar and max. temperature 300°C), acid resistant steel (DN 20-100 for pressure up to 40 bar and max. temperature 300°C, or cast steel (DN 20-200 for pressure up to 40 bar and max. temperature 450°C). Valves made of grey cast iron(DN 15 – DN 125) and cast steel (DN 20 – DN 125) can be equipped with a soft sealing disc. The valve can be used in shipbuilding, food, chemical, heating, energy, petrochemical and refrigeration industry. It can be used also in installation with drinking water, sewage, gas, glycol, diathermic oil, industrial water, steam and other natural and aggressive media, depending on theresistance of materials usedfor the construction ofthe valve.

Features

flange dimension according to PN EN 1092
valves made according to PN EN ISO 4126-1
wide range of parameters and DN
high tightness
for valves with soft sealing
quiet work of valve
raised tightness of closure
- protection of disc sealing surface in front of limestone (if the factor is industrial and drinking water) as well as against any small mechanical dirt

Anh chị vui lòng gọi điện hoặc gởi ZALO qua số 0902720814 / 0907450506 gặp Nhân viên kinh doanh để được tư vấn kỹ thuật và báo giá cụ thể hoặc email vào hòm thư: sales@pm-e.vn / info@pm-e.vn

VAN AN TOÀN ĐỒNG ZETKAMA NỐI REN FIG 781

1.000.000 đ

VAN AN TOÀN ĐỒNG ZETKAMA NỐI REN FIG 781

Thông tin kỹ thuật:

VAN AN TOÀN ĐỒNG NỐI REN TAY GẠT (BA LAN)
MODEL: 781T
Thân: đồng
Áp suất: 16 BAR
Nhiệt độ: 200 oC
Kết nối: REN

Proportional angle spring safety valve with threaded ends. The product is characterized by high tightness. Its body is made of brass. The product is available in sizes: DN 10-25. Its nominal pressure is 16 bar, and the maximum temperature is + 200°C. The valve can be used in drinking water, gas, glycol, industrial water, steam, compressed air and natural media systems. For valves with soft seal disc, sealing surface of the valve is protected against of limestone (if the factor is industrial and drinking water) as well as against any small mechanical dirt).

Safety Valve Zetkama

Features

valves made according to PN EN ISO 4126-1 high tightness
for valves with soft sealing quiet work of valve raised tightness of closure protection of disc sealing surface in front of limestone (if the factor is industrial and drinking water) as well as against any small mechanical dirt

Specification:

Material:Brass Nominal pressure:16 bar Nominal diameter:10-25 mm Temperature range:-10…+200°C Working position:Vertical

VAN CẦU HƠI ZETKAMA BA LAN - PN16 BELLOW SEAL FIG 234

1.000.000 đ

VAN CẦU HƠI ZETKAMA BA LAN - PN16 BELLOW SEAL FIG 234

Thông tin kỹ thuật

Material: Grey cast iron, nodular cast iron, nast steel, stainless Steel

Nominal pressure: 16, 25, 40 bar

Nominal diameter: 15-250 mm

Temperature range: -10…+400°C

Working position: Any

APPLICATION

INDUSTRY

SHIPBUILDING INDUSTRY

HEATING

REFRIGERATION AND AIR CONDITIONING

GLYCOL

INDUSTRIAL WATER

DIATHERMIC OIL

STEAMCOMPRESSED AIR

NEUTRAL FLUIDS

FEATURES
high tightness (leakproofness class – A acc. to EN – 12266 – 1)
compact settlement
environment-friendly
tests acc. to EN – 12266 – 1
flanges drilled according to EN 1092-2 for body material A, C
flanges drilled according to EN 1092-1 for body material F
face-to-face dimension according to EN 558 series 1

Thông tin kỹ thuật
Chất liệu: Gang xám, gang gật, thép nast, thép không gỉ

Áp suất danh nghĩa: 16, 25, 40 bar

Đường kính danh nghĩa: 15-250 mm

Phạm vi nhiệt độ: -10, + 400 ° C

Vị trí làm việc: Bất kỳ

ỨNG DỤNG
CÔNG NGHIỆP
CÔNG NGHIỆP SHIPBUILDING
SƯỞI
ĐIỆN LẠNH VÀ ĐIỀU KIỆN KHÔNG KHÍ
GLYCOL
NƯỚC THẢI CÔNG NGHIỆP
DẦU DIỆN
KHAI THÁC KHÔNG KHÍ
CẦU LÔNG
ĐẶC TRƯNG
độ kín cao (lớp chống rò rỉ - A acc. đến EN - 12266 - 1)
giải quyết nhỏ gọn
thân thiện với môi trường
kiểm tra acc. đến EN - 12266 - 1
mặt bích được khoan theo EN 1092-2 cho vật liệu cơ thể A, C
mặt bích được khoan theo EN 1092-1 cho vật liệu cơ thể F
kích thước mặt đối mặt theo EN 558 sê-ri 1
